HTTP requests, representations, and caching

Updated 06 Oct 2026

•
Definition
- •
- •
  HTTP → application-layer protocol defining how clients request resources and servers respond.
- •
  a resource can have multiple representations, such as different image formats or languages.
•
Clients
- •
  browsers, command-line tools, mobile applications, backend services, and other programs can act as HTTP clients.
•
Typical navigation
- •
  interpret the URL; reuse a suitable cahce response or connection where possible; resolve the hostname when needed; exchange a request and response. the application processes it, and a browser may request furtehr resources
•
Protocol and browser behavior
- •
  HTTP/1.1 message examples show a textual wire format; HTTP/2 and HTTP/3 use different framing.
- •
  Browser rendering is applictaion behavior build on top of HTTP

Messages

•
a request identifies a method, target, and protocol version; it may carry headers and a body.
•
a response carries a status code, headers, and sometimes a body.
•
headers carry metadata such as content type, accepted formats, cache policy, authentication, and connection details.
•
Body → contains representation data and is not necessarily HTML.

sequenceDiagram
    autonumber
    participant Client as Client Browser/App
    participant Server as Server Backend

    Note over Client,Server: 1. First request - no cache
    Client->>Server: GET /api/v1/users/101
    Note over Client,Server: Headers: Host, Accept, User-Agent
    Note over Client,Server: Body: empty
    Note over Server: Fetch data, generate ETag "a8f3-v1"
    Server-->>Client: 200 OK
    Note over Client,Server: Content-Type: application/json
    Note over Client,Server: ETag: "a8f3-v1"
    Note over Client,Server: Body: JSON id 101, name Alice

    Note over Client,Server: 2. Second request - ETag revalidation
    Client->>Server: GET /api/v1/users/101
    Note over Client,Server: If-None-Match: "a8f3-v1"
    Note over Server: ETag matches, data unchanged
    Server-->>Client: 304 Not Modified
    Note over Client,Server: ETag: "a8f3-v1"
    Note over Client,Server: Body: empty, use local cache

•
Methods
- •
  GET retrieves a representation and is intended to be safe.
- •
  HEAD asks for response metadata without the representation body.
- •
  POST commonly submits data or requests processing.
- •
  PUT commonly replaces a resource representation; PATCH applies a partial change; DELETE requests removal.
- •
  safety and idempotence describe intended semantics, not a guarantee that every server implementation is correct.
•
Status codes
- •
  Status classes → 1xx informational; 2xx success; 3xx redirection or revalidation; 4xx request/client problem; 5xx server problem. Examples: 200 OK, 304 Not Modified, 404 Not Found, and 500 Internal Server Error.
- •
  inspect headers and body as well as the status.
•
Testing
- •
  curl makes requests and inspects responses; the practicum varies methods and header. curl -i includes response headers; curl -I makes a HEAD request
•
Negotiation
- •
  clients express preferences using headers such as Accept, Accept-Language, and Accept-Encoding
- •
  servers describe the selected representation with headers such as Content-Type ad Content-Encoding
- •
  a server may return 406 Not Acceptable when it cannot meet acceptable constraints
•
Caching
- •
  vary tells caches which request headers influenced the selected representation
- •
  withotu correct variation metadata, a cahce could serve the wrong language or format
•
Cache policy
- •
  caching stores responses so later requests can avoid transferring or recomputing unchanged content
- •
  Cache-Control -> defines policy; max-age sets a freshness lifetime
- •
  no-store asks chaces not to store a response
- •
  no-cache permits storage but requires validation before reuse
•
Validation
- •
  a stale response can be checked with If-None-Match and an ETag, or If-Modified-Since and a modification date
- •
  if unchanged, the server can return 304 Not Modified and the client can reuse the stored body
- •
  expires, age, and shared-cache directives also affect behavior
•
Asset versioning
- •
  change an asset URL when its content changes, often by adding a content hash to the filename
- •
  Versioned assets -> allow long-lived caching; the HTML that points to them can use a shroter policy
